34
Adjustment and commissioning
8.10.4. On the pH/redox module
pH
mV
ORP
°C
°F
RTD
Mx:pH/ORP
"pH" = measured pH of the fluid
"mV" = measured pH of the fluid in mV
"ORP" = measured oxidation reduction potential of the fluid in mV
"°C" = measured temperature of the fluid in °C
"°F" = measured temperature of the fluid in °F
"RTD" = resistance of the temperature input in W
8.10.5. On the conductivity module
µS/cm
W.cm
°C
°F
RTD
TDS
%
USP
Mx:Conductivity
"µS/cm" = measured conductivity of the fluid
"
W.cm" = resistivity
"°C" = measured temperature of the fluid in °C
"°F" = measured temperature of the fluid in °F
"RTD" = input resistance of the temperature stage in W
"TDS" = quantity of dissolved solids in the fluid in ppm
"%" = mass concentration of the fluid (software option)
"USP" = state of the USP function
Type 8619
english
