Adjustment and commissioning
8.10. Process inputs or values
8.10.1. On the M0:MAIN board
DI1
None
DI1: Qv
DI2
AO1
AO2
DI2: Qv
DO1
DO2
SysSwitch
Fx:
M0:MAIN
1)
Warning
DI1: TotA
DI1: TotB
DI2: TotA
DI2: TotB
DI1: Hz
DI2: Hz
1)
Available on the device if the software option
"FLOW" is active
"Warning" = event generated by the multiCELL
"AOx" = analogue output
"DOx" = digital output
"System switch" = when the corresponding event is
configured and activated
"DIx" = digital input
"DIx Qv" = flow rate on digital input DIx
"DIx TotA" = totalizer A on digital input DIx
"DIx TotB" = totalizer B on digital input DIx
"DIx Hz" = frequency on digital input DIx
"Fx:" = result of configured and activated functions
8.10.2. On the input module
DI1
DI1: Qv
DI2
DI2: Qv
DI2:Hz
AI1
AI2
DI1:Hz
Mx:Entrées
1)
DI1: TotA
DI1: TotB
DI2: TotA
DI2: TotB
AI1Raw
AI2Raw
1)
Available on the device if the software option
"FLOW" is active
"AIx" = scaled process variable.
"DIx" = digital input
"DIx Qv" = flow rate on digital input DIx
"DIx TotA" = totalizer A on digital input DIx
"DIx TotB" = totalizer B on digital input DIx
"AIxRaw" = current or voltage standard signal on ana-
logue input AIx
"DIx Hz" = frequency on digital input DIx
8.10.3. On the additional outputs module
AO1
AO2
DO1
DO2
Mx:Outputs
"AOx" = analogue output
"DOx" = digital output
