Description
5. DESCRIPTION
5.1. Area of application
The 8619 multiCELL is a multifunction device intended to display, transmit and regulate various physical param-
eters. It can be used, for example, to manage a water treatment system (a boiler, a cooling tower or a reverse
osmosis system).
5.2. Description of the device name plate
8619 multiCELL
Supply: 12-36VDC
Temp: -10...+60 °C
IP65 PANEL (FRONT) IP20 (REAR)
S-N:1110
00560204
W44ML
Made in France
1
2
3
4
5
7
11
M0: 2xDI - 2xAO - 2xDO - SD CARD
M1: pH/ORP - PT100/1000
M2: RES COND 2/4 POLES PT100/1000
M3: 2xAO - 2xDO
M4:
M5:
M6:
Softw.:
00560204 W44ML
Made in France
6
8
9
}
10
12
Figure 1 : Example of a name plate
1. Type of device
2. Electrical power supply
3. Ambient temperature range
4. Protection rating
5. Serial number
6. Conformity logo
7. Manufacturing code
8. Device fitted with a memory card reader
9. Properties of the additional modules
10. Software options
11. Order code
12. Properties of the M0:MAIN board
