OPERATION MANUAL 088 PREAMP
Balance
Some spatial arrangements require a shift of the volume ratio between the two
reproducing channels. The volume shift is realized by reducing one of the two
stereo channels. It is possible to alleviate one channel of the preamp 088 up to 9 dB
(factor 2.8) in steps of 1 dB, and for specific situations to switch it off completely.
Select menu item BAL with the left rotary switch or the navigation buttons ► ◄ on
your remote control.
With the right rotary switch of the navigation buttons ▲ ▼ on your remote control
you may select the desired value:
<C> both stereo channels of the MAIN output will be reproduced at
the same volume level
-09R to -01R the right channel of the MAIN output will be reproduced with
reduced volume
OFF R the right channel of the MAIN output is muted
-09L to -01L the left channel of the MAIN output will be reproduced with
reduced volume
OFF L the left channel of the MAIN output is muted
The balance setting has no effect on the SURROUND input and on the TAPE output.
Initial volume
This menu item preselects the volume for the MAIN output of your device when it is
switched on.
Select menu item VOL with the left rotary switch or the navigation buttons ► ◄ on
your remote control.
With the right rotary switch or the navigation buttons ▲ ▼ on your remote control
you may select the desired value:
The range of selection reaches from 01 to 20 and -79 dB to -60 dB respectively,
in single steps.
If the setting LAST is chosen, the volume that was last selected will be used.
For security reasons, this is only possible up to a maximum volume of 20 and
-60 dB respectively.
The MC SETUP offers the adjustment of functions like AMPLIFICATION and
INPUT RESISTANCE.
NOTICE: This menu is only available if your preamp 088 is equipped with
a PHONO MC module and the input PHMC is selected.
The following chart provides an overview of all menu items, which may be adjusted
in the MC SETUP. The factory settings (defaults) are listed in brackets. Subsequent
to the chart you will find a detailed description of the menu items.
MENU ITEM DESCRIPTION DISPL AY VALUE
Amplification Adjusts PHONO MC amplification GAIN 54dB / 60dB /
(66dB) / 72dB
Input resistance Adjusts input capacitance of
PHONO MC module
LOAD 33Ω / 47Ω / 91Ω /
(120Ω) / 390Ω / 47kΩ
The MC SETUP MENU is activated by pushing down the switch key (10) on the front
panel or by longer pressing the AUDIO button (approx. 2 sec) on your remote
control. The display indicates the activation by showing MC SETUP, followed by the
first menu item.
To exit and automatically save the menu push down the switch key (10) or press the
MENU button on your remote control.
The MC Setup
