OPERATION MANUAL 088 PREAMP
List of Functions
Through factory settings a lot of functions are disabled to operate the
088 as a simple preamp. With the menus you are comfortably able to
activate the numerous options the 088 offers. In daily use these functions
are hidden. If wanted, factory settings can be reestablished.
The most important facts of the factory settings are:
•
The output MAIN OUT is the primary output of the preamp to connect to a power
amp or active loudspeakers. This output has an adjustable volume.
•
The output TAPE OUT is preset as a recording output to be connected to the
input of a recording unit e.g. of an analogue tape deck. This output will deliver
the maximum volume to the output of the selected input.
CAUTION: Never connect a power amp or active loudspeakers to this
output. Serious damage to your ears and equipments may occur.
•
The SURROUND input is supposed to be connected to the front-speakers
output of a volume adjustable surround decoder. The incoming signals on this
input will be put through to the MAIN output with maximum volume bypassing
the volume control of the 088.
CAUTION: Never connect a unit to this input without a volume-control.
Serious damage to your ears and equipments may occur.
Characteristics and functions of the preamp 088:
•
5 balanced input terminals, XLR 3pins. On demand operable as unbalanced
inputs by using adapter plugs.
•
Surround throughput for ideal integration in home theatre systems
•
Module slots for:
$
Line module, with unbalanced inputs, RCA
$
Phono MC module (optional), with balanced XLR 3 pins inputs, input sensitivity
and input resistance are selectable; connectable subsonic filters
$
Phono MM module (optional), with balanced XLR 3pins inputs, input sensitivity
and input impedance are selectable; connectable subsonic filters
$
D/A – converting module (optional), with S/P-DIF input (RCA) and USB slave
input, 069-technology with up sampling to 96kHz and 192kHz selectable
•
1 volume controlled balanced output with XLR 3pins terminals, supplied with
X-AMP MK2 modules
•
1 balanced TAPE output, XLR 3pins, with fixed volume for analogue tape
recording
•
1 headphone terminal, audio jack 6.3mm (1/4")
•
Global SETUP menu for individual setup of basic functions:
$
Input sensitivity adjustable from -6dB to +12dB for each input allowing
better volume control
$
Input names may be programmed individually
$
Display of serial number adjustable
$
Device control elements can be switched off manually to eliminate operating
error (child lock)
$
Reset to factory settings
•
Separate SETUP-Menus for individual presets:
$
Volume balance adjustable
$
Start up volume adjustable
•
Volume control and volume display adjustable in BURMESTER steps or dB steps
•
Output amplification for MAIN output may be selected between LOW and HIGH
to adjust to connected power amps or active loudspeakers
•
Display brightness adjustable in four steps, Display-Off-Function
•
Remote power up of other devices possible, Master/Slave over DC IN/OUT
connection
•
Burmester LINK module for external control via RS232 and USB
