Burnham FREEDOM - Page 82

82
KEY DESCRIPTION
(Quantity) Part Number
FCM070 FCM090 FCM120
102 DISP4D (1) 100450-01 (1) 100450-01 (1) 100450-01
103 Graphic Overlay Mounting Plate (1)100452-01 (1)100452-01 (1)100452-01
104 8-32 Lock Nut (4) 100449-01 (4) 100449-01 (4) 100449-01
105 Zinc Plated Brass Spacer (4) 101031-01 (4) 101031-01 (4) 101031-01
106 8-32 x ¾" Round Head Machine Screw (4) 101032-01 (4) 101032-01 (4) 101032-01
107 8-32 x ½" PH Machine Screw (1) 101033-01 (1) 101033-01 (1) 101033-01
108 8-32 Hex Nut (1) 101034-01 (1) 101034-01 (1) 101034-01
109 Resistor Clamp (1) 100468-01 (1) 100468-01 (1) 100468-01
114 Rear Panel (1) 101035-01 (1) 101035-01 (1) 101035-01
115 #10 x ½" Truss Hd Screws (12) 100423-01 (12) 100423-01 (12) 100423-01
116 1/8" Aluminum Pop Rivet (8) 101036-01 (8) 101036-01 (8) 101036-01
117 Draw Latch (2) 101037-01 (2) 101037-01 (2) 101037-01
118 Kennard #1110 Grommet (1) 101038-01 (1) 101038-01 (1) 101038-01
119 Top Panel (1) 101039-01 (1) 101039-01 (1) 101039-01
120 Vent Stub (1) 101040-01 (1) 101040-01 (1) 101040-01
121 Wall Hook (1) 101041-01 (1) 101041-01 (1) 101041-01
122 5/16" Flat Washer (2) 101042-01 (2) 101042-01 (2) 101042-01
123 5/16" x 2" Lag Screw (2) 101043-01 (2) 101043-01 (2) 101043-01
124 ¼-20 x ½" Phillips Pan Hd with Ext. Washer (8) 101044-01 (8) 101044-01 (8) 101044-01
125 Boiler Hanging Bracket (1) 101045-01 (1) 101045-01 (1) 101045-01
126 ¼-20 Nylon Insert Lock Nut (4) 101046-01 (4) 101046-01 (4) 101046-01
127 LH Side Panel (1) 101047-01 (1) 101047-01 (1) 101047-01
128 RH Side Panel (1) 101048-01 (1) 101048-01 (1) 101048-01
129 8" Long Bead Chain Lanyard (2) 101067-01 (2) 101067-01 (2) 101067-01
130 6-32 x ½ HWH Type F Self Tapping Screw (4) 100462-01 (4) 100462-01 (4) 100462-01
131 6-32 Wing Nut (4) 101068-01 (4) 101068-01 (4) 101068-01
132 Rubber Bumper (2) 101069-01 (2) 101069-01 (2) 101069-01
133 Pinhole Grommet (2) 101070-01 (2) 101070-01 (2) 101070-01
134 Draw Keeper (2) 101071-01 (2) 101071-01 (2) 101071-01
135 Bottom Panel (1) 101072-01 (1) 101072-01 (1) 101072-01
136 Bottom Pan Support Bracket (1) 101073-01 (1) 101073-01 (1) 101073-01
137 FCM Door Gasket (1) 101074-01 (1) 101074-01 (1) 101074-01
138 Upper Front Jacket Panel (1) 101075-01 (1) 101075-01 (1) 101075-01
139 U.S. Boiler Nameplate (1) 100846-01 (1) 100846-01 (1) 100846-01
140 10-32 x ½ Machine Screw (2) 101077-01 (2) 101077-01 (2) 101077-01
141 10-32 Screw Retainer (2) 101078-01 (2) 101078-01 (2) 101078-01
142 Nylon Spacer, #10 x 0.125 (2) 101079-01 (2) 101079-01 (2) 101079-01
143 3/16 x 1/2 Slic Pin (2) 101080-01 (2) 101080-01 (2) 101080-01
144 Lower Front Jacket Panel (1) 101081-01 (1) 101081-01 (1) 101081-01
145 Heyco 2" Window (1) 101082-01 (1) 101082-01 (1) 101082-01
146 Latch CM Cam (2) 101083-01 (2) 101083-01 (2) 101083-01
147 Straight Cam (2) 101084-01 (2) 101084-01 (2) 101084-01
150 FCM X3/X4 Harness (1) 101085-01 (1) 101085-01 (1) 101085-01
151 FCM X2 Harness (1) 101086-01 (1) 101086-01 (1) 101086-01
152 Line Voltage Blower Harness (1) 101087-01 (1) 101087-01 (1) 101087-01
153 FCM MCBA X1 Harness (1) 101088-01 (1) 101088-01 (1) 101088-01
154 Violet Jumper Wire (1) 100540-01 (1) 100540-01 (1) 100540-01
155 120VAC Pigtail Harness (1) 101089-01 (1) 101089-01 (1) 101089-01
156 FCM Display Harness (1) 101090-01 (1) 101090-01 (1) 101090-01
157 FCM Limit Harness (1) 101091-01 (1) 101091-01 (1) 101091-01
158 FCM Sensor Harness (1) 101092-01 (1) 101092-01 (1) 101092-01
159 FCM Blower Power Harness (Inner) (1) 101093-01 (1) 101093-01 (1) 101093-01
160 FCM Tacho Harness (1) 101094-01 (1) 101094-01 (1) 101094-01
161 Dungs Gas Valve Harness (1) 101095-01 (1) 101095-01 (1) 101095-01
162 Ignition Cable (1) 101096-01 (1) 101096-01 (1) 101096-01
PARTS LIST (Continued)
