Burnham FREEDOM - Assembly of Stainless Steel Venting

36
E. Assembly of Stainless Steel Venting
CAUTION
Vent systems made by Heat Fab, Protech, and Z-Flex rely on gaskets for proper sealing. When
these vent systems are used, take the following precautions:
• Make sure that gasket is in position and undamaged in the female end of the pipe.
• Make sure that both the male and female pipes are free of damage prior to assembly.
• Only cut vent pipe as permitted by the vent manufacturer in accordance with their instructions.
When pipe is cut, cut end must be square and carefully de-burred prior to assembly.
1) GeneralAssemblyNotes:
a) Wheretheuseof“silicone”iscalledforinthefollowinginstructions,useGERTV106orequivalentforthevent
collar.Airinletpipingsectionsaresealedwithanygeneral-purposesiliconesealantsuchasGERTV102.PVCair
inletpipingsectionsareconnectedwithPVCcement.
b) Longitudinalweldedseamsshouldnotbeplacedatthebottomofhorizontalsectionsofexhaustpipe.
c)Donotdrillholesinventpipe.
d)Donotattempttomixventcomponentsofdifferentventsystemmanufacturers.
2) MountingStainlesssteelventcollar-Theuseofstainlesssteelventingrequiresthestainlesssteelventcollar(P/N
101004-01whichreplacesthe80/125mmconcentriccollarsuppliedwiththeboiler.Toinstallthestainlesssteelvent
collar:
a) Removethesix#10sheetmetalscrewswhichattachthe80/125mmcollartotheboiler.
b) Removethecollarfromtheboiler(thismaybeeasierifatwistingmotionisappliedtothecollarwhileremovingit).
c) Lubricatethebrowngasketinthefemaleendoftheplasticventstub(insidetheboiler)withafewdropsofwater.
d) Pushthestainlesssteelventcollarontotheboilerwithaslighttwistingmotion.Makesurethatthestainlesssteelvent
adaptorisinsertedatleast1”intotheboilerstub.
e) SecurethecollarangetothetopoftheboilerwiththesheetmetalscrewsremovedinStep(a).
Figure 7.46: Installation of Stainless Steel Vent Collar
