XVI. Repair Parts (continued)
Key No. Description
Part Number
135 150 180
14, 15,
18, 29A
Boiler Water Gasket Repair Kit (includes (2)
22mm x 2mm O-rings, (2) connection clips, (2)
1-1/4 Union Gaskets, and (2) Pump Gaskets)
108191-01
16, 17,
17A
Return Pipe Repair Kit (includes return piping
assembly and ange hardware)
108211-01
19 Boiler Circulator Obtain Locally
20 Return Temperature Sensor 105910-01
21, 17,
17A, 22
Piping Block Kit 108209-01 108210-01
23, 27
Supply Pipe Repair Kit (includes supply piping
assembly and locknut)
108212-01
24 Supply Temperature Sensor 105911-01
25 T&P Gauge 108215-01
26, 26A Boiler Supply Flow Switch & O-Ring 105892-01
28 30 psi Relief Valve 81660319
29 Supply “U” Bend 108213-01 108214-01
13, 29A,
33, 35, 47
Plate HX (includes mounting bracket, hardware,
and ber gasket)
108204-01
29A, 30,
31, 32, 47
Valve Body Repair Kit (includes ttings for both
135 and 150/180)
108187-01
36 Valve Actuator 108186-01
37, 38 Boiler Water CSST set 108189-01 108190-01
