VII. Venting H. Assembly of Centrotherm InnoFlue Vent Systems
6. Installations using InnoFlue Flex (Vent Options 10 & 17):
WARNING
Asphyxiation Hazard. When using InnoFlue Flex, observe the following precautions:
• InnoFlue Flex may be damaged by handling at low temperatures. Do not bend, uncoil or attempt to
install if it has been stored at a temperature below 42°F without allowing it to warm to a higher
temperature rst.
• Do not bend InnoFlue Flex more than 45°.
• Instructions below reference the Centrotherm InnoFlue instruction manual. Not all vent congurations
shown in the Centrotherm manual are approved for use with this boiler.
RefertoCentrothermInnoFlueInstructionsforassemblyofallexcomponentsincludingthechimneycapandtheadaptor
to rigid InnoFlue at the base of the masonry or B vent chimney. In addition, observe the following requirements:
a. RefertotheappropriateVentoptioninTables7.13bor7.21foralistoftheprincipleexcomponentsrequired.Rigid
vent pipe by the same manufacturer will also be required for the run from the boiler to the base of chimney.
b. Masonry chimneys cannot be used for an air chase
c. B vent chimneys can only be used for an air chase (Vent option 10) if the B vent has the minimum size shown in Table
7.13b and is fully accessible for sealing of all joints and seams.
d. When Vent Option 10 is used, install a Tee of the same size at the base of the vent. Route the smooth section of InnoFlue
Flex (3”) through a cap in the base of this Tee. Use a Centrotherm IAWP03B wall plate and RTV to seal this penetration.
Install the Base Support using the Base support bracket as described in the InnoFlue installation manual.
Connection of the PVC air intake pipe to the side outlet of the tee is made using a cap and a PVC socket x male thread
adaptor. Cut a clearance hole in the cap for the male threads. Secure the adaptor to the cap using a 3” electrical conduit
lock nut. Seal all joints with RTV.
