Fig. 3/Fig. 4
In conjunction with MOS Fet Insert 6804U
and NO-contact pushbutton
In conjunction with Universal Relay Insert
6401U-102 and active Extension 6805U and
NO-contact pushbutton
L1
N
L1
L1
N
1N
L
L
N
6805U 6401U-102
NO-contact
pushbutton
6804U
NO-contact
pushbutton
