Installation | 5
Instruction Manual MINK MM 1102-1104 C VM_EN_en 11 | 32
5.3.1 Suction Connection
NOTICE
Ingress of foreign objects or liquids.
Risk of damage to the machine!
If the inlet gas contains dust or other foreign solid particles:
● Install a suitable filter (5micron or less) upstream from the machine.
Connection size(s):
– G1
Depending on the specific configuration ordered, other connection dimensions may apply.
5.3.2 Discharge Connection
NOTICE
Discharge gas flow obstructed.
Risk of damage to the machine!
● Make sure that the discharged gas will flow without obstruction. Do not shut off or throttle the
discharge line or use it as a pressurized air source.
Connection size(s):
– G1
Depending on the specific configuration ordered, other connection dimensions may apply.
Unless the aspirated air is discharged to the environment right at the machine:
● Make sure that the discharge line either slopes away from the machine or provide a liquid sep-
arator or a siphon with a drain cock, so that no liquids can flow back into the machine.
5.4 Filling Oil
NOTICE
Use of an inappropriate oil.
Risk of premature failure!
Loss of efficiency!
● Only use an oil type which has previously been approved and recommended by Busch.
For oil type and oil capacity see Technical Data [➔25] and Oil [➔26].
