4 | 32 Instruction Manual MINK MM 1102-1104 C VM_EN_en
2 Product Description
SI/OUT
MM 1102 C VM
Silencer variant 2
MTB
DA
NP OFP
EB
IN
OUT
OSG ODP
SIIN
MM 1104 C VM
Silencer variant 1
CD
Description
IN Inlet connection OUT Discharge connection
OFP Oil fill plug ODP Oil drain plug
OSG Oil sight glass MTB Motor terminal box
SI Silencer CD Condensate drain (optional)
EB Eye bolt DA Directional arrow
NP Nameplate
NOTE
Technical term.
In this instruction manual, we consider that the term ‘machine’ refers to the ‘vacuum pump’.
NOTE
Illustrations
In this instruction manual the illustrations may differ from the machine appearance.
