Installation | 5
Instruction Manual MINK MM 1102-1104 C VM_EN_en 9 | 32
5 Installation
5.1 Installation Conditions
NOTICE
Use of the machine outside of the permitted installation conditions.
Risk of premature failure!
Loss of efficiency!
Take care that the installation conditions are fully complied with.
~20 cm
~20 cm
~20 cm
~20 cm
Make sure that the ambient conditions comply with the Technical Data [25].
Make sure that the environmental conditions comply with the protection class of the motor and
the electrical elements.
Make sure that the installation space or location is protected from weather and lightning.
Make sure that the installation space or location is vented such that sufficient cooling of the ma-
chine is provided.
Make sure that the oil sight glass (OSG) remains easily visible.
Make sure that enough space remains for maintenance work.
Make sure that the machine is placed or mounted horizontally, a maximum of 1° in any direction
is acceptable.
Make sure that all provided covers, guards, hoods, etc. are mounted.
If the machine is installed at an altitude greater than 1000 meters above sea level:
Contact your Busch representative, the motor should be derated or the ambient temperature
limited.
