Commissioning | 6
0870207738_RA_RC0400-0630C_USA_-_IM_en 13 / 32
5.4.1 Wiring Diagram Three-Phase Motor
The wiring diagram for the electrical connection is located in the terminal box or on the
nameplate of the motor.
If the pump is supplied with a motor starter, it is preset at the factory in accordance with
the supplied motor. For other voltage requirements, contact the factory for motor and/or
starter information.
NOTE
See the motor manufacturer’s manual for start-up maintenance of the motor.
NOTICE
Incorrect direction of rotation.
Risk of damage to the vacuum pump!
Operation in the wrong direction of rotation can damage the vacuum pump in a short
time! Prior to starting-up make sure that the vacuum pump is operated in the right di-
rection.
Determine the intended direction of rotation from the arrow on the motor.
Jog the motor briefly.
Watch the fan of the motor and determine the direction of rotation just before the fan
stops.
If the rotation of the motor must be changed:
Switch any two of the motor phase wires.
6 Commissioning
NOTICE
The vacuum pump is shipped without oil.
Operation without oil will damage the vacuum pump in a short time!
Prior to commissioning, the vacuum pump must be filled with oil, see Filling Oil
[11].
CAUTION
During operation the surface of the vacuum pump may reach temperatures of more than
158°F.
Risk of burns!
Avoid contact with the vacuum pump during and directly after operation.
