AHE Air-oil heat exchanger BAF Baffle filter
DA Directional arrow EB Eye bolt
EF Exhaust filter EPG Exhaust pressure gauge
FV Float valve (on RA version only) GB Gas ballast valve (standard on RA)
IN Suction connection LS Level switch
MTB Motor terminal box NP Nameplate
ODP Oil drain plug OF Oil filter
OFP Oil fill plug OS Oil separator
OSG Oil sight glass OUT Discharge connection
TS Temperature switch
