BUSCH Zebra - Storage; Installation; 5.1 Installation Conditions

Storage | 4
0870169116_RH0003-0021B_-0002_IM_en 7 / 28
Machine weight:
see the technical data or the nameplate (NP)
For RH 0010 B and RH 0015 B:
For RH 0021 B:
For RH 0003 B:
Due to its light weight (16 kg / 35 lbs), it can be handled with care by hand
• Check the machine for transport damage.
In case of the machine being secured to a base plate:
• Remove the fixations.
4 Storage
• Seal all apertures with adhesive tape or reuse provided caps.
In case of storage of more than 3months is scheduled:
• Wrap the machine in a corrosion inhibiting film.
• Store the machine indoors, dry, dust free and if possible in original packaging
preferably at temperatures between 7 ... 40 °C (45 ... 104 °F), less than 85%RH
(relative humidity).
5 Installation
5.1 Installation Conditions
~10 cm
~3.93 in
~10 cm
~3.93 in
~10 cm
~3.93 in
~10 cm
~3.93 in
• Make sure that the environment of the machine is not potentially explosive.
• Make sure that the ambient conditions comply with the Technical Data [}23].
• Make sure that the environmental conditions comply with the protection class of the
motor.
