BUSCH Zebra User Manual

Technical Data | 13
0870169116_RH0003-0021B_-0002_IM_en 23 / 28
13 Technical Data
RH 0003 B RH 0010 B RH 0015 B RH 0021 B
Pumping speed
(50Hz / 60Hz)
m³/h 2.4 / 2.9 8.1 / 9.7 12 / 14.4 16.9 / 20.2
cfm 1.4 / 1.7 4.8 / 5.7 7.1 / 8.5 9.9 / 11.9
Ultimate total pressure
(without gas ballast valve)
hPa (mbar) abs. 6.7 x 10
-3
Torr abs. 5 x 10
-3
Ultimate total pressure
(with gas ballast valve)
hPa (mbar) abs. 6.7 x 10
-2
Torr abs. 5 x 10
-2
Nominal motor rating
Single-phase motor
(50Hz / 60Hz)
kW 0.2 / 0.2 0.4 / 0.4 0.55 / 0.55 0.75 / 0.9
Nominal motor rating
Three-phase motor
(50Hz / 60Hz)
kW N/A 0.4 / 0.4 0.55 / 0.55 0.7 / 0.7
Nominal motor speed
Single-phase motor
(50Hz / 60Hz)
min
-1
1460 / 1760 1455 / 1750 1435 / 1730 1470 / 1770
Nominal motor speed
Three-phase motor
(50Hz / 60Hz)
min
-1
N/A 1460 / 1760 1460 / 1760 1460 / 1760
Noise level (EN ISO 2151)
with oil mist separator and single-
phase motor
(50Hz / 60Hz)
dB(A) ≤ 52 / 53 ≤ 52 / 54 ≤ 54 / 56 ≤ 59 / 61
Noise level (EN ISO 2151)
with oil mist separator and three-
phase motor
(50Hz / 60Hz)
dB(A) N/A ≤ 49 / 52 ≤ 52 / 55 ≤ 59 / 63
Water vapour capacity
(with gas ballast valve)
g / h 5 37.8 40.4 73
Ambient temperature range °C 7 … 40
°F 45 … 104
Relative humidity at 30 °C (86 °F) 85%
Max. internal pressure hPa (mbar) gauge 300
Ambient pressure Atmospheric pressure
Cooling method Air cooled
Max. oil capacity l 0.8 1 1.1 1.1
qt 0.8 1.1 1.2 1.2
Oil type VSD 026 VMA 055 VMA 055 VMA 055
Weight with
Single-phase motor
kg 16 29 31 42
lbs 35 64 68 93
Weight with
Three-phase motor
kg N/A 26 29 34.5
lbs N/A 57 64 76
14 Oil
VSD 026 VMA 055
Viscosity at 40°C (104°F) 26 cSt (mm
2
/s) 55 cSt (mm
2
/s)
Part number 1L packaging 0831 169 419 0831 169 415
Part number 5L packaging N/A 0831 169 416
