Fiskars Boats, Inha Works Ltd 2010
25 (31)
BOAT'S TECHNICAL INFORMATION
Buster Lx
MAIN DIMENSIONS
Length overall, m 5.04
Hull length, m 5.04
Max. beam, m 1.98
Draught at max. load, m 0.32
Height from water surface, m 1.32
Dry weight (no engine or load), kg 410
Unloaded weight (engine and battery), kg*) 540–560
Displacement mass with full load, kg**) 1,070
CARRYING CAPACITY
Recommended max. number of people 6
Recommended max. load, kg ***) 450
TANK CAPACITIES
Pontoon foam, I 682
Fuel tank, I 53
PERFORMANCE
Recommended max. engine output, kW (hp) 45 (60)
Performance at max. output, knots 32
ELECTRICAL SYSTEM
Voltage 12 V DC
Recommended battery capacity, Ah 1x80 Ah
*) Weight alternation is influenced by the engine brand and model.
**) The maximum overall weight is the boat’s unloaded weight plus the maximum recommended load
with the basic equipment and contents of fixed tanks. The unloaded weight is in this case as per the
maximum engine weight.
**) The following incidental loads are permissible in addition to the maximum number of people and
cargo on board:
INCIDENTAL LOADS
Basic equipment, kg 20
Contents of fixed fuel tanks, kg 40
Due to the production process, there may be small variations in the main dimensions
and volumes.
