Butler CAPTURE 4 - Page 3

INSTRUCTION, USE AND
MAINTENANCE MANUAL
GB
Page 3 of 67
KEY
1 – Wheel support
2 – Upper tool
3 – Upper roll
4 – Lower roll
5 – Lower tool
6 – Multifunctional console
7 – Pedalboard
8 – Complete column
9 – Air preparation filter
10 – Locking ring nut
11 – Lifting device
12 – Console
13 – Ring for assembly grease support
14 – Pedal-operated inflation device
15 – Entrainer
16 – Pedal for operations assent
17 – Activator support
KEY
1 – Wheel support
2 – Upper tool
3 – Upper roll
4 – Lower roll
5 – Lower tool
6 – Multifunctional console
7 – Pedalboard
8 – Complete column
9 – Air preparation filter
10 – Tubeless inflation unit
11 – Locking ring nut
12 – Lifting device
13 – Console
14 – Ring for assembly grease support
15 – Pedal-operated inflation device
16 – Entrainer
17 – Pedal for operations assent
18 – Activator support
CAPTURE 4 - CAPTURE 4 FI
7104-M007-4_B
FIG. 1 - CAPTURE 4
FIG. 2 - CAPTURE 4 FI
