Butler CAPTURE 4 - 15 Technical Data; Weight; Dimensions

INSTRUCTION, USE AND
MAINTENANCE MANUAL
GB
Page 42 of 67
15.2 Dimensions
Fig. 62
CAPTURE 4
15.0 TECHNICAL DATA
Recommended air supply pressure: ............. 8 - 10 bar
Invemotor Speed: ......................................... 18 rpm
Invemotor Power: ......................................... 1,5 kW
Recommended electric supply:
.......................... single-phase 200÷265V - 50/60 Hz
Wheel maximum diameter: ..................... 50”/52”/54”
Wheel maximum width: .......................................15”
Rim locking diameter:
..................................... 10”-30”÷12”-32”÷14”-34”
Bead-breaking power per roll (10 bar): ........ 1200 kg
Vertical bead breaker max. opening: ............ 900 mm
Gear noise: ................................................... dBA 76
15.1 Weight
Model without tubeless inflation: ....................514 kg
Model with tubeless inflation: .........................520 kg
CAPTURE 4 - CAPTURE 4 FI
7104-M007-4_B
