Butler CAPTURE 4 - Page 55

LISTA DEI COMPONENTI - LIST OF COMPONENTS - TEILELISTE
LISTE DES PIECES DETACHEES - LISTA DE PIEZAS
Pag. 55 di 67
SCHEMA ELETTRICO 11/20
ELECTRICAL SCHEME 11/20
SCHALTPLAN 11/20
SCHEMA ELECTRIQUE 11/20
ESQUEMA ELECTRICO 11/20
Tavola N°A - Rev. 3 710405530
BROWN+GRAY+RETURN 11A 11B
11A
11B
SV. FORWARD V11
SV. BACK V11
10A
10B
SV. FORWARD V10
SV. BACK V10
Rit. 6A, 6B, 7, 8A + UPPER FEELER PIN-
LOWER, FEELER PIN MICRO
+10A+10B
710465530 GREEN+YELLOW
710465520 GREEN
CAPTURE 4
CAPTURE 4 FI
7104-M007-4_B
