BWT Bewamat 75A - Installation Diagram

11
11
AUS
Firmly attach the flushing water hose into the
ushing-water connection (9).
Route the ushing water hose at an incline to the
sewage system connection (drain) and secure the
end with the supplied xing material to prevent it
moving around when under pressure.
Put the overow hose (18 x 24) on the overow
(10). Secure it with cable ties and route it with an
incline of at least 10 cm to the sewage system
connection (drain).
Connect the unit as shown in the installation dia-
gram. The ushing water and overow hoses may
not be connected or restricted.
The ushing water and overow hoses must be
connected to the sewage water system at least
20 mm above the highest waste water level (unim-
peded drainage).
9
10
6.1 Installation diagram
> 20 mm
Dosing-
unit
Filter
Floorsen-
sor
Sewage
drain
Waterstop
