BYD M6 - Page 137

BYD M6 AUTO Owner’s Manual
Air Conditioning (A/C) System 2-23
running for a long time. When
efficiency of the A/C and heater drops
sharply, or when window fogging
occurs easily under the exterior
circulation mode, check whether the
filter must be replaced.
1. Open the glove box and pull off the
damper, as shown in the figure above.
2. Lift up the glove box in the direction
of the arrows to remove the glove box.
Pay attention to the limit posts on both
sides.
3. Press the latches on both sides to
release them, and then pull out the
filter.
4. Compress the filter toward the
center, and take out the filter from the
bracket.
5. When the filter is dirty, you can
clean it by blowing compressed air
from the rear side. Install the filter to
check whether it functions normally; if
not, replace the filter.
6. When installing the filter, pay
attention to hold it in the bracket,
preventing it from dropping off.
Limit post
