Definition of M6 Engine Compartment Relays
Position Definition Position Definition
K1-1 Front blower relay K1-4 High speed cooling fan
K1-2 Compressor relay K1-5 High speed condenser fan
K1-3 Rear defroster relay
M6 Engine Compartment Distribution Box Assembly (figure above)
Position Definition Position Definition Position Definition
F1-1 Right high beam (10A) F1-10 Low (high) speed fan (30A) F1-19 ABS pump motor (40A)
F1-2 Left high beam (10A) F1-11 High speed fan (20A) F1-20 Power seat (40A)
F1-3 Left low beam (10A) F1-12 Compressor (7.5A) F1-21 Front blower (40A)
F1-4 Right low beam (10A) F1-13 Turn signal lights (15A) F1-22 Main fuse (125A)
F1-5 2# ignition switch (25A) F1-14 Horn, braking lights (40A) F1-23 Main fuse reserve
F1-6
Width-indicator light
(15A)
F1-15 Rear defroster (40A) F1-24 Window motor (50A)
F1-7 MCU (7.5A) F1-16
Door lock, MICU constant power
(40A)
F1-25 1# ignition switch (50A)
F1-8 Front fog lights (25A) F1-17 ABS ECU (25A)
F1-9 EMS (15A) F1-18 EMS (40A)
