Byrobot PETRONE - Drive Kit Installation

19
5. Parts Replacement and Accessories
5. Parts Replacement and Accessories
5-3 Drive Kit (Sold separately)
1)Remove the propeller guard
from the Petrone body.
2) Remove the Motor Bracket
from the Petrone body.
3) Assemble drive-only motor bracket
and drive-only wheel.
4) Insert the drive-only motor bracket
to the front of Petrone Body.
5) Assemble the bracket and
the perpendicular wings.
6) Insert the assembled wing Bracket
to the rear of Petrone Body
2) Cautions
Prepare the Drive Kit.
1) Preparation
3) Replacement
7) Assemble the horizontal wings
on the wing brackets on both sides.
8) Completed. After the battery is installed,
you must use after changing to the
Drive Mode.
Attach the front motor bracket of Drive Kit deep inside as
shown above.
