【Internet way】Select ‘PPPoE’
【NAT】Check ‘NAT’ feature；NAT is mainly used for address translation function of local
network and external network. The default is checked enable status. If you do
not check this option, maybe you can’t surf the internet.
【Enable Vlan】We can set this option according to your network plan. If there is vlan in
the network for internet, we have to check ‘Enable VLAN’ option. If not,
we needn’t check this option, which will be VLAN transparent mode.
【Vlan ID】Configure this option according to our network plan.
【MTU】The default is 1492；we have to change to lower MTU, such as 1400, if we can
ping the DNS but not access the website via WEB broswer.
【User Name】Type PPPoE account, normally offered by ISP, for Internet；
【Password】Type PPPoE password, normally offered by ISP, for Internet；
【Service Mode】Select Internet；Normally, select ‘ Internet ’ in the route mode.
【LAN DHCP Disable】Don’t check this option；Normally, Terminal , connected to the
HGU ONU, will get an IP address from the ONU’s IP pool.
Therefore, we needn’t check this option to get the IP address.
【 Bind port 】 Bundel the physical ports (Lan port 1-4 and wireless) with PPPoE WAN
connection.
Note: By default, all LAN ports and WIFI data are not bound by this WAN connection (a
LAN and WIFI SSID can only be bound to a WAN conection at the same time).
