EP203 AUTOMATIC EXTINGUISHER PANEL
Page 22 of 45 • EP203 AUTOMATIC EXTINGUISHER PANEL INSTALLATION MANUAL • Approved Document No. DFU0002032 Rev 4
PROGRAMMING THE EP203 PANEL
Three levels of control are available on the EP203 panel: General User (Access Level 1),
Authorised User (Access Level 2) and Engineer (Access Level 3) as detailed below:
Note: For detailed information on how to use the general and authorised user controls,
refer to the EP203 panel User Manual/Log Book (Approved Document No. DFU0002031).
Gen eral Us er Controls (Access Level 1)
The functions that can be performed in Access Level 1 are:
• Manually activate the extinguisher release
• Mute the internal sounder.
Also, by pressing the ‘menu’ button, the LCD unit displays the following Access Level 1 menu:
Authorised User Controls (Access Level 2)
The functions that can be performed in Access Level 2, by turning the panel-mounted
keyswitch to the ‘accessed’ position, are:
• Manually activate the extinguisher release
• Mute the internal sounder
• Silence the alarm sounders
• Resound the alarm sounders
• Reset an alarm condition.
Also, the LCD unit displays the following Access Level 2 menu:
