EP203 AUTOMATIC EXTINGUISHER PANEL
Page 24 of 45 • EP203 AUTOMATIC EXTINGUISHER PANEL INSTALLATION MANUAL • Approved Document No. DFU0002032 Rev 4
ACCESS LEVEL 3 MENUS
Overview
Menu
Sub-Menu
Description
Display Faults
n/a
Displays all faults on the system
Display Dis/mnt
n/a
Displays all disablements on the system
Zones in Test
n/a
Displays all detection zones that are in test mode on the system
Display RSUs
n/a
Displays all Remote Status Units connected on the system
Disable Exting
Disables/enables the extinguishant system
Disable Zone
Disables/enables detection zones
Disable Sounder
Disables/enables fire sounders
Disable SndrDel
Disables/enables fire sounder delay
Disable Input
Disables/enables monitored inputs
Disable Relay
Disables/enables auxiliary relay outputs
Disablem ents
Disable RSU
Disables/enables Remote Status Units
Zone Selection
Selects the zone combination that starts the extinguishant
release sequence
Ext. Delay
Sets the countdown duration before the release of extinguishant
Ext. Duration
Sets the duration of the firing signal to the extinguishant
output
Flooding Time
Sets the duration for release of extinguishant
Extract Option
Selects the ventilation extract option
Extract Time
Sets the duration for the ventilation extract fan operation
Flow Option
Selects the flow switch
Sounder Delay
Sets the delay duration before the fire sounders are activated
RSU Learn
Finds all RSUs on the system and updates the panel’s database
Ext. O/P EOLs
Selects the number of extinguisher circuit terminations
Mode Exceptions
Selects the default setting mode when the mode input is in Fault
and/or Disabled
Earth Fault
Disables/enables the panel’s earth fault monitoring circuitry
Man Rel Mode
Selects either delayed, or immediate release of extinguishant
Zone Trigger
Enables a short circuit condition on the three detection zones
Resound Fire
Disables/enables the panel’s resound on fire
Commissioning
Clean Start
Clears the panel’s memory back to its default factory settings
Walk Test
Puts detection zone(s) into walk test mode
Test Relays
Tests the panel’s auxiliary relay outputs
Test Sounders
Tests the panel’s sounder circuits
Monitoring
Applies a constant monitoring voltage
Show PSU Stats
Displays status of the panel’s PSU and standby battery
Engineering
Version Numbers
Displays the panel’s software version and checksum
Note: A Stop Flooding ‘floating’ menu is also displayed for a level 3 user when an extinguishant
release is in progress. Selecting this menu terminates the release of extinguishant.
