USER MANUAL & LOG BOOK • Approved Document No. DFU5020000 Rev 3 • Page 13 of 24
CAST XFP 16 & 32 ZONE ANALOGUE ADDRESSABLE FIRE ALARM PANEL
Pressing the 5 and 6 buttons will scroll the display through all active fire conditions. More detailed
information (if applicable) can be viewed by pressing the panel’s More Information button. To return
to the main access level 1 menu press the Escape
3 button.
Display fault events
This function is only available if there are active faults on the system. If available, select the menu
option and press the Accept
4 button once. A window similar to the one below will appear:
Pressing the
5 and 6 buttons will scroll the display through all active faults. More detailed
information (if applicable) can be viewed by pressing the panel’s More Information button. To return
to the main access level 1 menu press the Escape
3 button.
Display disablements
This function is only available when there are active disablements on the system. If available, select the
menu option and press the Accept
4 button once. A window similar to the one below will appear:
Pressing the
5 and 6 buttons will scroll the display through all active disablements. To return to
the main access level 1 menu press the Escape
3 button.
Display zones in test
This function is only available if there are zones being tested. If available, select the menu option and
press the Accept
4 button once. A window similar to the one below will appear:
Pressing the
5 and 6 buttons will scroll the display through all zones in test mode. To return to the
main access level 1 menu press the Escape
3 button.
Testing the panel’s lamps
This function tests the panel’s lamps (LED indicators and display) to ensure they are working correctly.
Select the Lamp Test menu option and press the Accept
4 button. All of the panel’s LED indicators will
illuminate steady for approximately two seconds and its display will progressively block fill. The panel’s
internal sounder will also sound. Upon completion, the panel will return to the main access level 1
menu. If any of the indicators fail to illuminate or the display does not function correctly, report the
fault(s) to the designated site engineer and make a note of it in the Fire Alarm Log Book (page 22).
Displaying the panel’s alarm counter
This function displays the total number of times the panel has been in a fire alarm condition (a
maximum of 999 counts). Select the Display Alarm Counter menu option and press the Accept
4
button once. The display will show the total number of times the panel has been in a fire condition
since it was installed AND the total number of times it has been in alarm since the alarm counter was
last cleared, for example:
To return to the main access level 1 menu press the Escape
3 button.
Zone 1: Ground Floor
There are faults on this zone
1st Zone: 1: Shop floor
On: This Panel: Is Disabled
Zone 1: North Stairs
Is On Test
LAMP TEST?
Display Alarm Counter
AL1
Total Alarms = 12
Alarms since 01/01/21 = 7
