4.2.5 Winding up the Liner in Peel-Off mode
6
5
7
Fig. 10 Guidance of the material in peel-off mode
In Peel-Off mode, the labels are removed after printing, and only the liner is wound up internally.
1. Lift the pinch roller (4) off the rewind assist roller (5).
2. Remove labels from the rst 100 mm of the liner.
3. Guide liner to the rewinder (2) around the dispense plate (6) and the rewind assist roller (5).
4. Hold rewinder (2) rmly and turn knob (3) clockwise until it stops.
5. Push liner under a bracket (1) of the rewinder (2) and turn knob (3) counterclockwise until it stops.
The rewinder is fully spread, thus gripping the liner rmly.
6. Turn rewinder (2) counterclockwise to tighten the liner.
7. Slightly loosen top xing screw at the locking system with Allen key and position the pinch roller (4) centrally to the
liner.
8. Close the locking system and tighten top xing screw at the locking system.
9. Turn lever (7) clockwise to lock the printhead.
The label roll is loaded for use in peel-off mode.
