8 Media
8.2 Device Dimensions
Fig. 20 Device dimensions
Dim. Designation Dim. in mm
A2+ A4+ A4.3+ A6+ A8+
IP Distance printhead - peel-off edge 13,5 -
IC Distance printhead - cut edge 18,8
IT Distance printhead - tear-off edge 13,5
J Distance 1st heating point - material edge
203 dpi
300 dpi
600 dpi
-
2,0
2,0
2,0
2,0
2,0
2,0
2,0
-
0,4
3,1
-
-
2,0
-
K Print width
203 dpi
300 dpi
600 dpi
-
54,2
57,0
104,0
105,6
105,6
104,0
108,4
-
168,0
162,6
-
-
216,0
-
SX Distance gap/reective sensor -
material edge
i.e. permissible distance of reex or cut-out
marks to the material edge
5 - 26 5 - 53
SY Distance gap/reective sensor -
printhead
46,0
Table 9 Device dimensions
Gap sensor
& Reective sensor
Printhead
Peel-off edge
Tear-off edge
Cut edge
Feed direction
