CAB a2+ Operator's Manual

6
7
22
23
24
25
26
27
28
29
22 Power switch
23 Power connection jack
24 Slot for PC Card Type II
25 Slot for CompactFlash memory card
26 Ethernet 10/100 Base-T
27 2 USB master ports for keyboard,
scanner or service key
28 USB high-speed slave port
29 Serial RS-232 C port
Fig. 3 Connections
30
30 Support bracket (A8+ only)
for additional bearing of the roller and printhead
assemblies and the ribbon hubs
Fig. 4 Support bracket A8+
2 Installation

CAB a2+ Specifications

General

Brand	CAB
Model	a2+
Category	Label Maker
Language	English
