CAB XD4M User Manual

26 26
8 Media
8.3 Reex Mark Dimensions
Fig.20 Reexmarkdimensions
Dim. Designation Dim. in mm
H Print zone height 5 - 1000
A Print zone distance > 2
V Feed length > 7
L
Widthofreexmark > 5
M
Heightofreexmark 3 - 10
X Distance mark - middle of media track
=Distancegap/reectivesensor-middleofmediatrack
-53 - ±0
Y Sensor recognized virtual print zone front edge Front edge of mark
• Reexmarksmustbeonthebacksideofthematerial(liner).
• Materialsensorforreexmarksonthetopsideonrequest.
• Specicationisvalidforblackmarks.
• Recognition of colored marks may fail.  Preliminary tests are needed.
Table10 Reexmarkdimensions
Feed direction
