Your vehicle has a visual optical headlamp aiming
system equipped with horizontal aim indicators. The aim
has been preset at the factory and should need no
further adjustment. This
is
true even though your
horizontal aim indicators may not fall exactly on the
"0
(zero) marks on their scales.
If your vehicle is damaged in an accident, the headlamp
aim may be affected. Aim adjustment
to
the low beam
may be necessary
if
it is difficult to see lane markers (for
horizontal aim), or
if
oncoming drivers flash their high
beams at you (for vertical aim).
If
you believe your
headlamps need to be re-aimed, we recommend that
you take your vehicle to your dealer for service.
However, it is possible for you to re-aim your headlamps
as described in the foiiowing procedure.
Notice:
To
make sure your headlamps are aimed
properly, read all the instructions before beginning.
Failure to
follow
these instructions
could
cause
damage to headlamp parts.
The vehicle should be properly prepared as follows:
The vehicle should be placed
so
the headlamps are
25
ft,
(7.6
m) from a light colored wall or other flat
surface.
0
The vehicle must have all four tires on a perfectly
level surface which is level all the way to the wall
or other flat surface.
The vehicle should be placed so it is perpendicular
to the wall or other flat surface.
The vehicle should not have any snow, ice or mud
attached
to
It.
The vehicle should be fully assembled and all other
work stopped while headlamp aiming
is
being done.
full tank of fuel and one person or
160
Ibs.
(75
kg)
on the driver's seat.
Tires should be properly inflated.
The vehicle should be normally loaded with a
5-49
