I
Relavs
I
Usage
I
27
Horn
31
Daytime Running Lamps
30
Fog Lamps
29
Headlamp Low Beam
28
Headlamp High Beam
I-
32
I
Air Conditioner Clutch
I
I
33
I
Not Used
I
34
Not Used
35
Accessory
36 Starter
1
37
Cooling Fan
1
38
lanition
1
39 Cooling Fan Series/Parallel
40 Cooling Fan
2
Circuit
I
Breakers
I
Usage
I
41
I
Starter
The spare fuses are located in numbers 48 through
52.
The fuse puller is located in number 53.
Removing
the
Rear
Seat Cushion
Notice:
The battery and main fuse blocks are
located under the rear seat cushion. The battery’s
ground terminal and some relay wires are exposed.
To help avoid damage to the battery and wires,
be careful when removing or reinstalling the seat
cushion.
Do
not remove covers from covered parts.
Do
not store anything under the seat, as objects
could touch exposed wires and cause a short.
To remove the rear seat cushion, do the following:
1.
Pull up on the front of the cushion to release the
front hooks.
2.
Pull the cushion
up
and out toward the front of the
vehicle.
