Cafection Encore lite - Internal View Diagram

ENCORE LITE Rev. 3 05/2018
www.cafection.com 800-561-6162
10
SERVICE & INSTALLATION MANUAL for Cafection's Encore Lite
3.3 Internal View
Filter paper
Soluble mixing
chamber
Brew group
Spout
Internal
waste bin
Main board
(see section3.6)
Coffee grinder
(behind the filter paper
roll and protector)
COM connection
Flash card
Fan
Coffee
Hot water
Soluble products
#1 and #2
Soluble
canisters
S
p
o
u
t
-
T
o
p
V
i
e
w
Reference Drawings
Overflow cup
