SERVICE & INSTALLATION MANUAL for Cafection's Encore Lite
3.8 Bean Hopper Installation
The hopper is already installed on the
brewer when shipped. To remove it,
follow the steps below.
1. Unlock the bean hopper. The lock is
located on top of the lid.
2. Remove the bean hopper back plate.
3. Push the bean hopper backward and
then lift it.
4. Repeat steps in reverse order to
reinstall.
Transmissions (3x)
Motors (3x)
Bean hopper
Bean hopper
back plate
Bean hopper
door lock
