CAIRE Eclipse 5 - Introduction to the Eclipse 5 Oxygen System

Personal Ambulatory Oxygen System Provider Technical Manual
5
PN 20631679 Rev D
INTRODUCTION TO THE ECLIPSE 5 OXYGEN SYSTEM
FRONT
Control Panel
Handle
External Power
Receptacle
Power Cord
Retainer
Oxygen
Outlet Port
FAA
Approval
Icon
BACK
Power Cartridge Latch
Exhaust Vent
Power
Cartridge
(Battery)
FAA Approval Icon
Cart
Attachment
Location
Air Inlet
Filter
EDAT Service Port
(Not for Patient Use)
Rating Label &
Serial Number
Location
ECLIPSE 5
AC POWER SUPPLY
WITH NEMA POWER CORD
DC POWER SUPPLY
UNIVERSAL CART
POWER CARTRIDGE

BATTER
Y
PN: 5941-SEQ
PN: 5942-SEQ
PN: 7082-SEQ
PN: 5991-SEQ
