Personal Ambulatory Oxygen System Provider Technical Manual
82
PN 20631679 Rev D
MAINTENANCE AND REPLACEMENT PARTS
Preventative Maintenance Parts
Description CAIRE Inc. Part Number
Preventive Maintenance Kit (includes * items) 5022-SEQ
* Air Inlet Filter 7028-SEQ
* Compressor Intake Filter 8069-SEQ
* HEPA Filter (Old /New) 6986-SEQ / 9765-SEQ
* 9V Battery 8098-SEQ
* Wire Ties (Qty 10) 5268-SEQ
EDAT (Service Tool) 5535-SEQ
Replacement Parts List
Description CAIRE Inc. Part Number
AC Power Supply 5941-SEQ
ATF Module Assembly, Eclipse 5 20626702
Cable harness, SPI/ I2C 8076-SEQ
Carton Assembly, Eclipse 5 Oxygen System SP3581-SEQ
Case Bottom Cover 20623857
Case Bottom Subassembly, Eclipse 5 SP20623837
Case Top Subassembly, Eclipse 5 SP20623840
Compressor Box Assembly, Universal SP5999-SEQ
Control System PCBA, Eclipse 5 SP4043-9-SEQ
DC Power Supply 5942-SEQ
Foot, bottom 6956-SEQ
Handle 6963-SEQ
Inlet Filter 7028-SEQ
Membrane Panel Overlay, Eclipse 5 SP20618461
Nut, Outlet 2777-SEQ
Outlet Assembly, Oxygen 3922-SEQ
Power Manager PCBA, Eclipse 5 (Not Field Replaceable) SP5932-4-SEQ
Power Cartridge 7082-SEQ
Product Tank Assembly SP4378-SEQ
Rubber Gasket (Channel Seal) 4106-2-SEQ
Screw, M2x10 Pan Head Machine (Cooling fan) 6961-210-SEQ
Screw, M3x10 Plastite (CS pcb, Product Tank, 9V Batt harness) 6950-310-SEQ
Screw, M3x12 Pan Head SEM (Top to Bottom case, BBB PCB) 6974-312-SEQ
Screw, M4x16 Pan Head Machine (ATF to Bottom case) 6961-416-SEQ
Screw, M4x16 Pan Head Machine (Compressor to Bottom Case) 6961-420-SEQ
Tubing, Silicone, 3/16” ID SP6981-SEQ
Tubing, Silicone, 2mm ID SP4101-SEQ
Tubing, Braided, 5/16” ID SP3534-SEQ
Washer, M3 Flat 6985-03-SEQ
Washer, M4 Flat 6985-04-SEQ
Washer, M4 Flat Fender 3568-SEQ
Wire harness, 9V 1076-SEQ
Wire Harness, Service Port 7012-SEQ
Wire Harness, External Power, Eclipse 5 4063-SEQ
Kit, Preventative Maintenance 5022-SEQ
