CAIRE Eclipse 5 - Recommended Operating Environments; Specifications; Available Settings

12 - ENG PN 21182453 C | User Manual
Eclipse 5
Recommended Operating Environments
For proper use of the device, the following chart
provides important information concerning the
recommended operating environments, or operating
conditions.
Specifications
Operating
Temperature
50º F to 104º F (10º C to 40º C)
Operating
Humidity
10% - 95% at an 82.4° F (28° C)
dew point
Transport/Stor-
age
Temperature
-4º F to 140º F (-20º C to 60º C)
Humidity: Up to 95% Non-Con-
densing
Electrical Use no extension cords. Use no
electrical outlets controlled by a
switch.
Altitude 0 – 13,123 feet (0 - 4,000
meters)
Placement DO NOT block the air inlet (top
back cover) or the exhaust vent
(back bottom left). Place device
a minimum of 3 inches (7.5
cm) away from walls, draperies,
furniture, etc.
Environment Must be smoke, pollutant, and
fume free.
Operating Time 24-hours a day when connected
to an external AC or DC power
source.
Oxygen
Concentration
90%+5.5%/-3% @ sea level
Dimensions 19.3 high x 12.3 wide x 7.1 deep
(inches), 49.0 height x 31.2 wide
x 18.0 deep (CM)
Weight Eclipse 15 lbs., Battery 3.4 lbs.
Power AC Power (100-240 VAC, 50-60
Hz; DC Power (12V nominal);
Battery (Quantity (2) 95 W-Hr
battery packs each containing
7.92 gm of lithium content)
Nominal
Battery
Recharge Time
1.8 to 5.0 hrs recharge time to
achieve 80% capacity (dependent
upon the flow)
Alarms/Alerts Loss of power, Low Battery, Low
Therapeutic O2 Output, O2 flow
outside normal limits. No Inspi-
ration detected in Pulse Dose
Mode, Unit Malfunction
O2
Concentration
Indicator
Green Light=Normal
Yellow=Caution <85%
Outlet
Pressure
Nominal: 7.0 psig
Maximum: 14.0 psig
Sound Level 48 dBA at 3.0 LPM Continuous
Flow Mode; 40 dBA at 3.0 Pulse
Dose Setting; 59 dBA while
alarming
Applied Part Cannula
The expected service life is a minimum of ve years.
WARNING: USE OF THIS DEVICE AT AN
ALTITUDE ABOVE 13,123 FEET (4,000
METERS) OR OUTSIDE TEMPERATURE
OF 50º F TO 104º F (10º C TO 40º C) OR
A RELATIVE HUMIDITY ABOVE 95% IS
EXPECTED TO ADVERSELY AFFECT THE
FLOWRATE AND THE PERCENTAGE OF
OXYGEN AND CONSEQUENTLY THE
QUALITY OF THE THERAPY.
Note: If the Oxygen Concentrator has been stored
for and extended period of time outside its normal
operating temperature range, the unit should be
allowed to return to normal operating temperature
before use. The recommended time is 3 hours.
Available Settings
The Eclipse 5, including the cannula and other
accessories, are specied for use at the following
specic ows.
Continuous Flow Settings
in LPM
Pulse Dose Setting Bolus
Size (mL)
0.5
-
1.0
16
1.5
24
2.0
32
2.5
40
3.0
48
-
56
- 64
- 72
- 80
- 88
- 96
- 128
- 160
- 192
Minimum oxygen concentration (82%).
