CAIRE Eclipse 5 - Alarms Table

PN 2118245 C | User Manual 21 - ENG
Eclipse 5
Alarms Table
Alarm LCD Text Green Yellow Audio Code
All OK, warm-up done NO ALARM ON OFF OFF 000
Warm-up O2 < 85% O2 LOW ON ON No Beeps 008
No breath detected (less than
45 seconds)
NO ALARM ON OFF OFF 000
No breath detected (exceeding
45 seconds)
P <--> C ON ON 1 alarm beep, repeat
every 20 seconds
200
One wire communication loss ONE WIRE ON OR
OFF
ON 1 alarm beep, repeat
every 20 seconds
100
Cannot charge battery CHARGER ON OR
OFF
ON 1 alarm beep, repeat
every 20 seconds
001
Ambient pressure fail AMB PRESS ON OR
OFF
ON 1 alarm beep, repeat
every 20 seconds
004
O2 < 85% (After warm-up) O2 LOW OFF ON 1 alarm beep, repeat
every 20 seconds
008
Flow rate error > +/-10% FLOWRATE OFF ON 1 alarm beep, repeat
every 20 seconds
020
Warm battery > 60°C WARM BAT ON ON 1 alarm beep, repeat
every 20 seconds
002
Low battery
(5% remaining battery
capacity)
LOW BAT ON ON 1 alarm beep, repeat
every 20 seconds
010
Loss of power ******** OFF ON 1 alarm beep, repeat
every 20 seconds for
200 seconds
040
Malfunction FAIL XX OFF ON 1 alarm beep, repeat
every 20 seconds for
200 seconds
080
