4 - ENG PN 21182453 C | User Manual
Eclipse 5
Quick Start Guide
1 Unpack Your Eclipse 5 2 Getting to Know Your Eclipse 5
Review all Warnings, Cautions and additional de-
vice information in the rest of this manual. Become
familiar with the key features of the Eclipse 5 and
the User Control Panel.
Eclipse 5
AC Power Supply
DC Power Supply
Universal Cart
Power Cartridge (battery)
FRONT
Control Panel
Handle
Oxygen
Outlet Port
FAA
Approval
Icon
Rating Label &
Serial Number
Location
BACK
Power Cartridge
Latch
Exhaust Vent
Power
Cartridge
(Battery)
Cart
Attachment
Location
Air Inlet
Filter
Service Port
(Not for
Patient Use)
To Next Page
