Function Options
[Factory settings] shown in brackets
rEu.d
Select output modes: Direct/Reverse
Caution: Settings affect fail safe state.
SP1 SP2
[1r.2d]
Reverse Direct
1d.2d
Direct Direct
1r.2r
Reverse Reverse
1d.2r
Direct Reverse
Select Reverse on SP1 for heating and Direct for
cooling applications.
rEu.L
Select SP1/2 LED indicator modes
SP1 SP2
[1n.2n]
Normal Normal
1i.2n
Invert Normal
1n.2i
Normal Invert
1i.2i
Invert Invert
SPAn [0.0] to ±25% sensor maximum -1999–2500 in Linear
Sensor span adjust
For recalibrating to align readings with another instrument e.g. External Meter, data logger.
See Full Operating Manual (ADVANCED SETTINGS).
ZEro [0.0] to ±25% sensor f/s -1999–2500 in Linear
Zero sensor error (see Sensor span adjust above).
ChEK [oFF] on
Select control accuracy monitor
rEAD [Var] hi Lo
Read control accuracy monitor
tECh [Ct A] CT b Ct 1 Ct 2 Ct 3 Ct 4 oS 1 uS oS 2
Read Autotune tuning cycle data (see Operating Manual)
UEr
Software version number
rSET [nonE] ALL
Resets all functions to factory settings
Caution: This selection will lose all of the current settings.
LEVEL 4
Access to level 4 is gained through
UEr
in level 3. Press and hold ▲ and ▼ for 10 seconds.
Enter level 4 at
Lock
, release ▲ and ▼ together. Display reads
LoCK nonE
Program security using
Lock [nonE]
Select from three
Lock
options: Press and hold ✱, press ▲ to index.
LEV.3
locks level 3, 4, A (and C when fitted)
LEV.2
locks level 2, 3, 4, A (and C when fitted)
ALL
locks all functions (including C when fitted)
Note: Any locked functions and options can still be read.
Press ▼ to access following functions.
Function Options
[Factory settings] shown in brackets
ProG [Auto] StAY
Program mode auto-exit switch
Auto-exit returns display to normal if 60 seconds of key inactivity, select
StAY
to disable
no.AL [oFF] on
Disable SP2 alarm annunciator -AL-
Select on to disable -AL-
di.SS dir 1 to 32 [6]
Display sensitivity
dir
= direct display of input
1
= maximum,
32
= minimum sensitivity
dEr.S 0.1 to 1.0 [0.5]
Derivative sensitivity
SEt.L (oFF) on
Remember next menu exit point and use as new
menu entry point, except when exit is in Level 1.
LEVEL P See PROGRAMMER Section, page 11.
LEVEL C COMMS SETTINGS; visible only when Comms option
fitted.
Additional in depth information on controller operation is available in the APPGUIDE.PDF
available for down load from www
.cal-controls.com
LEVL 4
✢
✢
✢
✢
Will be affected by dECP settings in Level A
✢
LEVEL 3 CONTINUED
LEVL P
LEVL C
