28 — Ma c h i n i s t ca l c ™/ Ma c h i n i s t ca l c ™ Pr o
3. Store as the Diameter:
=d
DIA 0.228 INCH
4. Enter the RPM:
750R
RPM 750.
5. Calculate the Cutting Speed:
C
* CUT 14. M/MIN
6. Return calculator to U.S. Mode:
gSSS+
US UnITS
* Repeated presses of
C
will toggle through the inputs and outputs,
starting with the entered Diameter.
rPm (SPINDlE SPEED)
RPM is the rotational speed of the spindle in revolutions per
minute. In a milling machine or drill, the Spindle Speed is the
rotation of the attached cutting tool. In a turning machine, it is
the rotation of the attached workpiece. RPM can be calculated
given values for Diameter and Cutting Speed.
RPM - Milling
Calculate the Spindle Speed (RPM) when milling with a 3/8” bit
at a Cutting Speed of 300 sfm (surface feet per minute):
(cont'd)
KEYSTROKE DISPLAY
