Operatinginstructions
Electric-SystemEVS34/12-DS/IU
CALIRA ElectronicGmbH&Co.KG
Lerchenfeldstr.987600KaufbeurenTel.+49(0)8341/9764-0Fax+49(0)8341/67806
Internet:http://www.calira.deEmail:info@calira.de
Mainsconnection
Commissioning
Chargingabattery
Prerequisites
Connectthemainscabletothepowerdistributionofyourcaravan.Connectthe
green/yellowcabletotheearthcircuit!
Checkthatalltheconnectionsarefirmandsecure.
Finally,connecttothemainsthroughtheIECpowerconnectorandconnectto
thetowingvehiclethroughthecouplingplug.
TheEVSisoperationalassoonasitisconnectedtothemains.Powerisgiven
tothesupplybattery(batteryII)andtotheconsumersonthecontinuous+12 V
output. Theconsumersontheother+12 V outputsareonlysuppliedwhen
themainswitchison.
Beforebreakingormakingdirect-currentconnections,e.g.thechargingcableat
thebattery,thedevicebeswitchedoffatthemains.
Batterieswithshort-circuitedcellsmustnotbechargedExplosionhazarddueto
thegenerationofoxyhydrogengas!
Thebatterymusthavearatedvoltageof12voltandaminimumcapacityof60
Ah.Insufficientchargingtakesplaceifthebatteryisbelowthisvalue.Ifthe
batteryvoltageislessthan1.5 V,chargingwillnottakeplaceduringmains
operation.
Itisessentialthatthemainsdistributoris
switchedoffatthemainsbeforeconnectingor
disconnectingcablestothemainsdistributor!
Neverchargebatterieswithshort-circuitedcells!
