Page 25 of page 38
C
ALIX
2364 ONT I
NSTALLATION
G
UIDE
3 - 2364 ONT I
NSTALLATION
S
TEPS
3.8.2 Connecting the Auxiliary Po
wer
Figure 3-15
: Auxiliary powe
r
Use 16AWG copper wire. Calix recommends a wire
insulation strip leng
th of 7mm (0.275").
+20V to +57V
Return
27
29
