Locally on the E-Series:
On the Navigation Tree, click the unit.
In the Work Area, click Profiles > Service > Multicast > Multicast Maps >
Profiles.
2. In the menu, click Create to open the Create Multicast Maps dialog box.
3. In the Name box, enter a descriptive name for the map, and then click Create.
4. In the list of existing multicast maps, click the map name to select it.
5. In the menu, click Create to open the Create Multicast Address Range dialog box.
6. Reference the table above to configure the parameters.
7. Click Create to add the multicast address range to the multicast map.
8. Repeat Steps 5 through 7 to include another multicast range in the multicast map.
9. Associate the multicast map when creating a multicast profile.
For CLI:
create mcast-map <m-name>
add range to-mcast-map <m-name> mcast <m-range>
delete mcast-map <index>
remove range <index> from-mcast-map <m-name>
set mcast-map <old-name> name <new-name>
set mcast-map <m-name> range <index> mcast <m-range>
show mcast-map [m-name]
Creating a Multicast Whitelist Map and Ranges
This topic describes how to create a multicast white list and IP address ranges that are
assigned to the list. You can use multicast white lists to create complex channel line-ups on a
per subscriber basis without the use of Middleware. The map is then applied when adding a
video service to an ONT or xDSL Ethernet port.
Define IPTV packages by specifying multicast channel ranges, organizing diverse channel
line-ups into more manageable groups, known as maps:
Each system supports:
up to 128 multicast white list maps where each supports up to 32 channel sequences
Each video service supports:
up to 16 multicast white list maps per subscriber service
