Parameter Description Valid Options
Queue 5 Min
Bandwidth
Minimum bandwidth for queue 5, specified in Mbps. The allowed range
is 1–10000.
1–10000 Mbps
Queue 6 Rate Shaping rate for queue 6, specified in Mbps. The allowed range is 1–
10000.
1–10000 Mbps
Queue 6 Min
Bandwidth
Minimum bandwidth for queue 6, specified in Mbps. The allowed range
is 1–10000.
1–10000 Mbps
Queue 7 Rate Shaping rate for queue 7, specified in Mbps. The allowed range is 1–
10000.
1–10000 Mbps
Queue 7 Min
Bandwidth
Minimum bandwidth for queue 7, specified in Mbps. The allowed range
is 1–10000.
1–10000 Mbps
Queue 8 Rate Shaping rate for queue 8, specified in Mbps. The allowed range is 1–
10000.
1–10000 Mbps
Queue 8 Min
Bandwidth
Minimum bandwidth for queue 8, specified in Mbps. The allowed range
is 1–10000.
1–10000 Mbps
Port Shaping Rate Aggregate shaping rate for the port, specified in Mbps. The allowed
range is 1–10000.
Alternately, select none to indicate that shaping should not be done.
none (or keyword
"unshaped")
Enter Value: 1–10000 Mbps
or select a value from the list
Port Burst Size Aggregate burst size for port, specified in Kbits. The allowed range is 1
to 128000.
Alternately, select auto to automatically calculate the burst size.
auto (or keyword "auto")
Enter Value: 1–128000
Kbits or select a value from
the list
* Required field
To create a class of service
1. Access the profile page:
 From CMS:
 On the Navigation Tree, click CMS.
 In the Work Area, click Profile > E3-48C/E5-48/E7 > CoS Profile.
 Locally on E-Series:
 On the Navigation Tree, click the unit.
 In the Work Area, click Profiles > CoS > Ethernet > Create.
2. Reference the table above to configure the parameters.
3. Click Create.
4. Associate the class of service profile to an Ethernet port so traffic is sent at a particular
rate by controlling the queueing of packets.
5. See Configuring an Ethernet Port (on page 21).
For CLI:
create cos-queue-cfg <queue name> [queue-*-rate|queue-*-min-bw|port-
rate|port-burst-size]
