Calix E7-2 User Manual

118
Proprietary Information: Not for use or disclosure except by written agreement with Calix.
© Calix. All Rights Reserved.
Parameters
You can provision the following parameters for multicast white lists and ranges:
Parameter Description Valid Options
Name*
Name of the multicast white list.
32 character string
ID* Index value designating the multicast range in the
multicast white list map. You can leave the value, or
select another (1-32).
1-32
Start IP Address* First address in the multicast range. Any multicast address, lower than the end
IP address (224.0.0.0 - 239.255.255.255)
End IP Address* Last address in the multicast range.
May be 0 (for single address), if non-0 must be in Mcast
range and greater than start IP address value.
Any multicast address, higher than the end
IP address (>239.255.255.255)
*Required fields
To create a multicast white list and address ranges
1. Access the profile page:
 From CMS:
 On the Navigation Tree, click CMS.
 In the Work Area, click Profile > E3-48C/E5-48/E7/ONT > Profile >
Service > Multicast White List.
 Locally on the E-Series:
 On the Navigation Tree, click the unit.
 In the Work Area, click Profiles > Service > Multicast White List.
2. In the menu, click Create to open the Create Multicast White List dialog box.
3. In the Name box, enter a descriptive name for the list, and then click Create.
4. In the list of existing multicast white lists, double-click the name to select it.
5. In the menu, click Create to open the Create Multicast White List Range dialog box.
6. Reference the table above to configure the parameters.
7. Click Create to add the multicast address range to the multicast white list.
8. Repeat Steps 5 through 7 to include another multicast range in the multicast white list.
9. Associate the multicast white list when creating a video service.
See Configuring IP video Services for instructions.
