79
Proprietary Information: Not for use or disclosure except by written agreement with Calix.
© Calix. All Rights Reserved.
The DSL port MUST be set to PTM-Override=ATM in order for Multi-VC
support to work
The System will not allow a tag action that specifies a PVC match list to be added
if PTM-Override=Auto
If PTM-Override=Auto, only the provisioned Fallback PVC will work.
Tagged match rules can match on any combination of the following:
Outer tag
VLAN-ID
P-bit values
Tag Protocol Identifier (TPID) can also be specified at the E-Series egress Ethernet
port interface, but defaults to 0x8100
Configuration guidelines
If a residential gateway (RG) at the subscriber's premises classifies traffic into VLANs,
then for each service type, create a match list with a tagged rule that matches the service
VLAN.
In E7 R2.1 and earlier, downstream priority-tagged traffic that does not meet any match
criteria will be passed through unmetered. In E7 R2.2 and above, this is also true for
VDSL2 and GPON (if the PON CoS setting allows it).
Match list and rule parameters
You can provision the following parameters for match list and rules:
Parameter Description Valid Options
Name* Name of service match list. text string
S-VLAN (Outer Tag) VLAN ID of the outer tag (tagged match rules only). VLANs can be
specified by name or by numeric VLAN ID, which ranges from 1-4094. In
addition, "untagged" indicates that only untagged traffic should be
matched and "ignore" indicates that the VLAN ID should not be
text string, 1-4094,
untagged, ignore ‡
Default = ignore
Outer Pbit P-bit value of the outer tag (tagged match rules only). P-bit values are in
the range 0-7. Alternately "pbit-none" means the P-bit value is not
considered. If this parameter is not specified, "p-bit-none" is the default
